- Description
- The M113 HVMS is an Armoured Personnel Carrier that combines the ubiquitous M113 chassis with an Israeli-designed gun turret for fire support. The HVMS (High Velocity Medium Support) variant was developed by Israel Military Industries in the 1980s, mounting a 60 mm high-velocity gun in a stabilized turret to give mechanized units organic direct-fire capability against light armour and fortifications; it saw use with the Israel Defense Forces and was offered for export. Operated by a crew of three — driver, gunner, and commander — with seating for four passengers, the vehicle is tracked, weighs 15 tonnes, and is amphibious at 4 km/h. A 6V53 diesel engine delivers 212 horsepower for a 14.1 hp/t power-to-weight ratio and a top speed of 64 km/h.
The main armament is the 60mm IMI HVMS cannon in a three-round magazine with a 2 s reload, firing OTO HE-VT, M-54, and OTO HE ammunition; the turret has a stabilizer and a fire control system with laser rangefinder, lead computation, and 8× magnification. A coaxial .30 cal M1919 machine gun provides secondary fire. The HVMS gives the M113 credible firepower while retaining the chassis’s mobility and amphibious capability.
- Locomotion
- Tracked
- Amphibious
- Yes
- Supported classes
- +CrewmanInfantry (as passenger)
- Obtainment
- Free
| Team/Loadout | Cold War |
|---|---|
| Tier 4 |
| Weight | 15 t |
| Seating capacity | 7 |
| Driver | 1 |
| Gunner | 1 |
| Commander | 1 |
| Passenger | 4 |
| Max speed | |
| Forward | 64 km/h |
| Backward | 15 km/h |
| Amphibious | 4 km/h |
| Engine | 6V53 |
| Type | Diesel |
| Max RPM | 2,800 RPM |
| Horsepower | 212 hp |
| Power-to-weight ratio | 14.1 hp/t |
| Transmission | |
| Forward gears | 6 |
| Reverse gears | 2 |
| Automatic gearbox | Yes |
| Lower front plate | 11 mm–23 mm |
| Upper front plate | 16 mm–27 mm |
| Left cheek | 24 mm–83 mm |
| Right cheek | 24 mm–83 mm |
| Mantlet | 44 mm–89 mm |
| Hull side | 14 mm–24 mm |
Feature: Stabilizer
| Traversal | |
| Horizontal speed | 50 deg/s |
| Vertical speed | 25 deg/s |
| Vertical limits | -9° / 20° |
.30 cal M1919
| Reload speed | 4s |
| Magazine size | 225 |
| Ammo | Max |
| AP | * |
| Ammo models | |
| MG ammo | 11 |
Main sight
Feature: FCS
Fire control system
Feature: Lead
| Rangefinder | Laser |
| Vertical limits | -15°–30° |
| Zoom | 8x |
ID: "M113 HVMS"
