- Description
- The PT-76B is a Light Tank and an amphibious reconnaissance vehicle developed in the Soviet Union in the 1950s; it was widely exported and saw combat in numerous conflicts. Weighing 14 tonnes, it is crewed by three: driver, commander, and loader. The V-6 diesel produces 240 hp for 17.1 hp/t, 43 km/h on land and 10.2 km/h in water.
Main armament is the 76.2 mm D-56TM with HE (OF-350M), HEAT (BK-354M), and AP (BR-354), plus a coaxial 7.62mm PKT. The commander/gunner has a stabilizer and 4x telescope; there is no rangefinder or FCS. An engine smoke system is fitted. The PT-76B trades armour for amphibious capability and a useful gun, making it effective in wetlands and riverine operations.
- Locomotion
- Tracked
- Amphibious
- Yes
- Supported classes
- Crewman
- Obtainment
- Free
| Weight | 14 t |
| Seating capacity | 3 |
| Driver | 1 |
| Commander | 1 |
| Loader | 1 |
| Max speed | |
| Forward | 43 km/h |
| Backward | 6.6 km/h |
| Amphibious | 10.2 km/h |
| Engine | V-6 |
| Type | Diesel |
| Max RPM | 2,100 RPM |
| Horsepower | 240 hp |
| Power-to-weight ratio | 17.1 hp/t |
| Transmission | |
| Forward gears | 5 |
| Reverse gears | 1 |
| Lower front plate | 19 mm–38 mm |
| Upper front plate | 52 mm–53 mm |
| Left cheek | 19 mm–171 mm |
| Right cheek | 19 mm–171 mm |
| Mantlet | 18 mm–37 mm |
| Hull side | 10 mm–13 mm |
| Engine smoke system | Yes |
| Electronic warfare | |
| IED jammer | No |
| Drone jammer | No |
Feature: Stabilizer
| Traversal | |
| Horizontal speed | 20 deg/s |
| Vertical speed | 6 deg/s |
| Vertical limits | -4° / 30° |
7.62mm PKT
| Reload speed | 6s |
| Magazine size | 250 |
| Ammo | Max |
| AP | * |
| Ammo models | |
| MG ammo | 6 |
Telescope sight
| Rangefinder | None |
| Zoom | 4x |
ID: "PT-76B"
