- Description
- The Merkava Mk.4M is a Main Battle Tank and an upgraded Merkava Mk.4 with improved electronics, defensive systems, and the Trophy active protection system; the Merkava family has been the backbone of Israeli armored forces since the late 1970s, with the Mk.4 entering service in 2004. The vehicle is tracked, weighs 81.4 tonnes, and is crewed by four — driver, gunner, commander, and loader — and is powered by an MTU 12V883 diesel engine producing 1,500 horsepower for an 18.4 hp/t power-to-weight ratio and a symmetric top speed of 64 km/h forward and reverse, with neutral steering and an automatic gearbox.
The main armament is the 120mm IMI MG251 smoothbore with a 5-second reload and M338, M339, DM12A1, and LAHAT ATGM ammunition, plus a coaxial 7.62mm FN MAG 60-40; the loader has a roof-mounted 60mm Soltam mortar for smoke and blast-frag. The turret has a two-plane stabilizer, laser and missile warning systems, smoke grenades, and a fire control system with lead and tracking, laser rangefinder, and Gen 2 green thermals; the commander has a CITV with laser and thermals. The Trophy APS uses two launchers with three charges each, intercepting projectiles between 70 and 1,000 m/s, and the vehicle is fitted with IED and drone jammers (no engine smoke system).
- Locomotion
- Tracked
- Supported classes
- Crewman
- Obtainment
- Shop
- Price
- 105,000 money
| Team/Loadout | Modern |
|---|---|
| Tier 4 |
Addons
250 points
| Weight | 81.4 t |
| Seating capacity | 4 |
| Driver | 1 |
| Gunner | 1 |
| Commander | 1 |
| Loader | 1 |
| Max speed | |
| Forward | 64 km/h |
| Backward | 64 km/h |
| Engine | MTU 12V883 |
| Type | Diesel |
| Max RPM | 2,700 RPM |
| Horsepower | 1,500 hp |
| Power-to-weight ratio | 18.4 hp/t |
| Transmission | |
| Forward gears | 5 |
| Reverse gears | 5 |
| Neutral steering | Yes |
| Automatic gearbox | Yes |
| Lower front plate | 97 mm–266 mm |
| Upper front plate | 207 mm–557 mm |
| Left cheek | 253 mm–2,800 mm |
| Right cheek | 336 mm–2,716 mm |
| Mantlet | 288 mm–530 mm |
| Hull side | 100 mm–370 mm |
| Engine smoke system | No |
| Electronic warfare | |
| IED jammer | Yes |
| Drone jammer | Yes |
| Horizontal limits | -120° / 120° |
| Vertical limits | -20° / 85° |
| Ammo | 2 launchers, 3 charges each |
| Cooldown | 1.5s Minimum time between interceptions |
| Reaction time | 0.3s |
| Interception speed | 70 m/s min, 1,000 m/s max |
| KE reduction | 10% |
Feature: LWS
Laser warning system
Feature: MAWS
Missile approach warning system
Feature: Stabilizer
Feature: Smoke grenades
| Traversal | |
| Horizontal speed | 34 deg/s |
| Vertical speed | 15 deg/s |
| Vertical limits | -7° / 20° |
7.62 mm FN MAG 60-40
| Reload speed | 6s |
| Magazine size | 200 |
| Ammo | Max |
| AP | * |
| Ammo models | |
| MG ammo | 18 |
Main sight
Feature: FCS
Fire control system
Feature: Lead
Feature: Tracking
| Rangefinder | Laser |
| Thermals | Green (Gen 2) |
| Vertical limits | -12°–30° |
| Zoom | 6.3°, 3.8°, 1.9°, 1° Vertical field of view |
| Thermal zoom | 6.3°, 3.8°, 1.9°, 1° Vertical field of view |
| Aspect ratio | 1.27 |
| Thermal aspect ratio | 1.27 |
Backup sight
Feature: FCS
Fire control system
Feature: Lead
Feature: Tracking
| Rangefinder | Laser |
| Vertical limits | -12°–30° |
| Zoom | 12x |
Feature: LWS
Laser warning system
Feature: MAWS
Missile approach warning system
Feature: Stabilizer
| Traversal | |
| Mouse aim | Yes |
| Horizontal speed | 60 deg/s |
| Vertical speed | 60 deg/s |
| Vertical limits | -10° / 55° |
7.62 mm FN MAG 60-40
| Reload speed | 6s |
| Magazine size | 200 |
| Ammo | Max |
| AP | * |
| Ammo models | |
| MG ammo | 18 |
CITV sight
| Rangefinder | Laser |
| Thermals | Green (Gen 2) |
| Zoom | 4x–14x |
MG sight
| Rangefinder | None |
| Zoom | 1x |
Feature: LWS
Laser warning system
Feature: MAWS
Missile approach warning system
| Traversal | |
| Horizontal speed | 60 deg/s |
| Vertical speed | 60 deg/s |
| Vertical limits | -25° / 25° |
60 mm Soltam Mortar
| Reload speed | 3.5s |
| Ammo | Max |
| Blast-frag High Charge | * |
| Blast-frag Low Charge | * |
| Smoke | * |
| Blast-frag Medium Charge | * |
| Ammo models | |
| Smoke mortar ammo | 20 |
ID: "Merkava Mk.4M"
