- Description
- The M36 Jackson is a Tank Destroyer mounting the 90 mm M3 gun on an open-topped turret atop the M10 Wolverine chassis. It was fielded in 1944 to give U.S. tank destroyer battalions a weapon capable of engaging Panthers and Tigers at range. The vehicle weighs 28.1 tonnes and is crewed by five: driver, gunner, bow gunner, commander, and loader. The Ford GAA V8 produces 450 horsepower for 16 hp/t and a top speed of 48 km/h. Main armament is the 90 mm M3 cannon with AP, APCR, and HE; a cupola 12.7 mm M2 provides anti-aircraft and local defense. The commander’s position has a stabilizer; the gunner uses a 4x/8x telescope with no rangefinder. The open turret improves visibility but leaves the crew exposed to small arms and shell splinters.
- Locomotion
- Tracked
- Supported classes
- Crewman
- Obtainment
- Free
| Team/Loadout | WW2 |
|---|---|
| Tier 3 |
| Weight | 28.1 t |
| Seating capacity | 6 |
| Driver | 1 |
| Gunner | 1 |
| AA gunner | 1 |
| Bow gunner | 1 |
| Commander | 1 |
| Loader | 1 |
| Max speed | |
| Forward | 48 km/h |
| Backward | 6.2 km/h |
| Engine | Ford GAA V8 |
| Type | Diesel |
| Max RPM | 2,600 RPM |
| Horsepower | 500 hp |
| Power-to-weight ratio | 17.8 hp/t |
| Transmission | |
| Forward gears | 5 |
| Reverse gears | 1 |
| Lower front plate | 52 mm–100 mm |
| Upper front plate | 62 mm–191 mm |
| Left cheek | 46 mm–184 mm |
| Right cheek | 46 mm–184 mm |
| Mantlet | 78 mm–199 mm |
| Hull side | 25 mm–49 mm |
| Traversal | |
| Horizontal speed | 60 deg/s |
| Vertical speed | 60 deg/s |
| Vertical limits | -15° / 25° |
Periscope sight
| Rangefinder | None |
| Zoom | 4x |
ID: "M36 Jackson"
