- Description
- The M1A1 SA is a Main Battle Tank and the principal production variant of the M1 Abrams family, fielded by the United States from 1985 with a 120 mm M256 smoothbore gun (license-built Rheinmetall L44), improved armour, and NBC protection. It became the backbone of U.S. armored forces in the Cold War and Gulf War and remains in service in upgraded forms. The 62.2 t vehicle is crewed by four (driver, gunner, commander, loader) and is powered by a Honeywell AGT1500 gas turbine producing 1,519 hp for 24.4 hp/t and 68 km/h.
The M256 fires M829 APFSDS, M830A1 variants, and M1028 canister; a 7.62 mm M240 is coaxial and a 12.7 mm M2 is commander-mounted, with a loader M240 optional. The gunner has a laser rangefinder, Gen 2 green thermals, and FCS with lead; the commander has a CROWS-style sight with Gen 1 thermals, FCS, and tracking. Stabilizer, smoke grenades, and engine smoke are fitted.
- Locomotion
- Tracked
- Supported classes
- Crewman
- Obtainment
- Free
| Team/Loadout | Modern |
|---|---|
| Tier 3 |
Addons
250 points
250 points
250 points
500 points
This addon does not change any of the data visible on this page
This addon does not change any of the data visible on this page
This addon does not change any of the data visible on this page
This addon does not change any of the data visible on this page
| Weight | 62.2 t |
| Seating capacity | 4 |
| Driver | 1 |
| Gunner | 1 |
| Commander | 1 |
| Loader | 1 |
| Max speed | |
| Forward | 68 km/h |
| Backward | 38 km/h |
| Engine | Honeywell AGT1500 |
| Type | Turbine |
| Max RPM | 3,000 RPM |
| Horsepower | 1,519 hp |
| Power-to-weight ratio | 24.4 hp/t |
| Transmission | |
| Forward gears | 4 |
| Reverse gears | 2 |
| Neutral steering | Yes |
| Automatic gearbox | Yes |
| Lower front plate | 269 mm–479 mm |
| Upper front plate | 250 mm–643 mm |
| Left cheek | 560 mm–1,667 mm |
| Right cheek | 555 mm–1,800 mm |
| Mantlet | 360 mm–470 mm |
| Hull side | 30 mm–138 mm |
| Engine smoke system | Yes |
| Electronic warfare | |
| IED jammer | No |
| Drone jammer | No |
Feature: Stabilizer
Feature: Smoke grenades
| Traversal | |
| Horizontal speed | 40 deg/s |
| Vertical speed | 24 deg/s |
| Vertical limits | -10° / 20° |
120mm M256
| Reload speed | 6s |
| Refill speed | 6s |
| Ammo | Max |
| M830A1 Proxy | * |
| M829 | * |
| M1028 | * |
| M830A1 PD | * |
| Ammo models | |
| Ready rack | 17 |
| Semi-ready rack | 17 |
| Hull ammo | 6 |
7.62mm M240
| Reload speed | 6s |
| Magazine size | 3,400 |
| Ammo | Max |
| AP | * |
| Ammo models | |
| Coax ammo | 1 |
Main sight
Feature: FCS
Fire control system
Feature: Lead
| Rangefinder | Laser |
| Thermals | Green (Gen 2) |
| Vertical limits | -15°–28° |
| Zoom | 3x, 10x |
| Thermal zoom | 7.5°, 3.75°, 2° Vertical field of view |
Backup sight
| Rangefinder | None |
| Zoom | 8x |
Feature: Stabilizer
| Traversal | |
| Mouse aim | Yes |
| Horizontal speed | 60 deg/s |
| Vertical speed | 60 deg/s |
| Vertical limits | -15° / 65° |
CROWS sight
Feature: FCS
Fire control system
Feature: Lead
Feature: Tracking
| Rangefinder | Laser |
| Thermals | White (Gen 1) |
| Vertical limits | -15°–65° |
| Zoom | 33.75°–2.475° Vertical field of view |
| Thermal zoom | 7.575°, 2.475° Vertical field of view |
| Aspect ratio | 1.333 |
| Thermal aspect ratio | 1.333 |
Feature: Stabilizer
| Traversal | |
| Mouse aim | Yes |
| Horizontal speed | 60 deg/s |
| Vertical speed | 60 deg/s |
| Vertical limits | -35° / 45° |
7.62mm M240
| Reload speed | 6s |
| Magazine size | 200 |
| Ammo | Max |
| AP | * |
| Ammo models | |
| MG ammo | 7 |
ID: "M1A1"
