- Description
- The M1117 ASV (Armored Security Vehicle) is an Armoured Personnel Carrier with a purpose-built, mine-resistant hull, developed for U.S. military police and internal security missions. It entered service in the late 1990s and was used in Iraq and Afghanistan for convoy escort and area security. The wheeled vehicle is crewed by a driver, gunner, commander, and two passengers, weighs 11 tonnes, and is amphibious at 4 km/h. A 6CTA8.3 diesel produces 270 horsepower for 24.5 hp/t and a top speed of 89 km/h.
The gunner operates a 40mm MK-19 grenade launcher and a 12.7mm M2 machine gun in a turret with smoke grenades and 2x–3.5x sights. The V-hull and armored cab improve protection against mines and small arms while keeping weight low for air transport and road mobility.
- Locomotion
- Wheeled
- Amphibious
- Yes
- Supported classes
- CrewmanEngineerInfantry
- Obtainment
- Shop
- Price
- 20,000 money
| Team/Loadout | Modern |
|---|---|
| Tier 1 |
Addons
This addon does not change any of the data visible on this page
| Weight | 11 t |
| Seating capacity | 5 |
| Driver | 1 |
| Gunner | 1 |
| Commander | 1 |
| Passenger | 2 |
| Max speed | |
| Forward | 89 km/h |
| Backward | 15 km/h |
| Amphibious | 4 km/h |
| Engine | 6CTA8.3 IMO 2 |
| Type | Diesel |
| Max RPM | 1,800 RPM |
| Horsepower | 270 hp |
| Power-to-weight ratio | 24.5 hp/t |
| Transmission | |
| Forward gears | 5 |
| Reverse gears | 1 |
| Automatic gearbox | Yes |
| Lower front plate | 19 mm–26 mm |
| Upper front plate | 16 mm–32 mm |
| Left cheek | 5 mm–105 mm |
| Right cheek | 7 mm–105 mm |
| Mantlet | 5 mm–83 mm |
| Hull side | 16 mm–36 mm |
Feature: Smoke grenades
| Traversal | |
| Horizontal speed | 50 deg/s |
| Vertical speed | 50 deg/s |
| Vertical limits | -8° / 45° |
Main sight
| Rangefinder | None |
| Zoom | 7x, 14x, 21x |
| Aspect ratio | 1.581 |
ID: "M1117 ASV"
