- Description
- The BM-21 Grad is a Rocket Artillery system mounted on a 6×6 truck, one of the most widely used multiple rocket launchers since its Soviet introduction in 1963. The Grad (hail) name refers to the 40-tube 122 mm launcher, which can saturate an area with 9M22/M21 HE-frag rockets at ranges of several kilometres. The 18.2 t wheeled vehicle is crewed by a driver and gunner; a ZiL-375 gasoline engine produces 180 hp (9.9 hp/t) for a top speed of 100 km/h.
The launcher has 7 deg/s horizontal and 5 deg/s vertical traverse with elevation from -2° to 55°, and a 6 s reload cycle. No rangefinder or fire control beyond the 1× sight is modelled in the data; in practice, Grad batteries rely on external targeting and fire-control assets.
- Locomotion
- Wheeled
- Hull breakExplodes when its engine is destroyed
- Yes
- Supported classes
- Crewman
- Obtainment
- Free
| Weight | 18.2 t |
| Seating capacity | 2 |
| Driver | 1 |
| Gunner | 1 |
| Max speed | |
| Forward | 100 km/h |
| Backward | 15 km/h |
| Engine | ZiL-375 |
| Type | Gasoline |
| Max RPM | 3,200 RPM |
| Horsepower | 180 hp |
| Power-to-weight ratio | 9.9 hp/t |
| Transmission | |
| Forward gears | 5 |
| Reverse gears | 1 |
| Lower front plate | 0 mm–26 mm |
| Upper front plate | 0 mm–26 mm |
| Left cheek | 5 mm–10 mm |
| Right cheek | 5 mm–10 mm |
| Mantlet | 5 mm |
| Hull side | 0 mm–13 mm |
| Traversal | |
| Horizontal speed | 7 deg/s |
| Vertical speed | 5 deg/s |
| Vertical limits | -2° / 55° |
122mm Grad
| Reload speed | 6s |
| Ammo | Max |
| 9M22/M21 HE-Frag | * |
| Ammo models | |
| Ammo2 | 40 |
Main sight
| Rangefinder | None |
| Zoom | 1x |
ID: "BM-21 Grad"
